More Steering Arms, Spindles, etc...	More Tie Rod Ends
Steering Wheels	Steering Motors or Hand Pumps for Fiat/Hesston & Long/UTB
Power Steering Cylinders, Kits, and Parts	Heavy Duty 2WD Front Axles for Loaders
Steering Gearboxes and Parts	Front Wheel Assist or 4x4 Parts

New Steering Gearbox*, for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50
Allis Chalmers 5040
Long 350, 360, 445, 460, 510, 560, 610
Fiat/Hesston 445, 450, 460, 470, 480, 480-8
500, 540, 550, 600, 640
*IMPORTANT--CHECK FIRST: mounting bolt pattern 2.75" x 3.75"
tapered spline 36MM at smallest diameter
24MM steering arm thread, splined steering wheel indexing.
2WD ONLY! Will make a 4WD steer in opposite direction!
$795.00US

Tractors with this style gearbox only
Steering Box Rebuild Kit*, for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50
Fiat/Hesston 445, 450, 460, 470, 480, 480-8
500, 540, 550, 600, 640
*consists of: steering column shaft & worm gear,
rocker (horizontal output) shaft, upper and lower column bearings,
rocker shaft bushings, and rocker shaft seal
Column Shaft 24 15/16" overall, tapered keyed shaft for steering wheel
2WD ONLY! Will make a 4WD steer in opposite direction!
$475.00US

Tractors with this style gearbox only
Steering Box Rebuild Kit*, for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50
Allis Chalmers 5045, 5050
Hesston 445, 450, 460, 470, 480, 480-8
500, 540, 550, 600, 640
*consists of: steering column shaft & worm gear,
rocker (horizontal output) shaft, upper and lower column bearings,
rocker shaft bushings, rocker shaft seal, and cover gasket
Column Shaft 25.5" overall, tapered keyed shaft for steering wheel
2WD ONLY! Will make a 4WD steer in opposite direction!
$475.00US

Tractors with this style gearbox only
Steering Box Rebuild Kit*, for:
Allis Chalmers 5040
Long 350, 360, 445, 460, 510, 560, 610
Universal UTB 350, 400, 445, 500
530, 550, 590 Super, 640
*consists of: steering column shaft & worm gear,
rocker (horizontal output) shaft, upper and lower column bearings,
rocker shaft bushings, and rocker shaft seal
Column Shaft 25 3/8" overall, splined shaft for steering wheel
2WD ONLY! Will make a 4WD steer in opposite direction!
$550.00US

Steering Box Rebuild Kit*, for:
Oliver/Cockshutt 1250
Fiat/Hesston 415
*consists of: steering column shaft & worm gear, upper and lower column bearings, rocker shaft bushings, and rocker shaft seal
Does NOT include a new rocker shaft!
$475.00US

Steering Column Shaft*, for:
Allis Chalmers 5040
Long 260, 310, 350, 360, 445, 460, 510, 560, 610
Universal UTB 300, 350, 400, 445, 500, 530, 550, 590, 600, 640
*25 3/8" overall, splined shaft for steering wheel
2WD ONLY! Will make a 4WD steer in opposite direction!
$275.00US

Steering Column Shaft*, for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50
Minneapolis Moline G350, G450
Fiat/Hesston 445, 450, 460, 470, 480, 480-8
500, 540, 550, 600, 640
*24 15/16" overall, keyed shaft for steering wheel
2WD ONLY! Will make a 4WD steer in opposite direction!
$275.00US

Steering Column Shaft*, for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50
Minneapolis Moline G350, G450
Fiat/Hesston 445, 450, 460, 470, 480, 480-8
500, 540, 550, 600, 640
*25.5" overall, keyed shaft for steering wheel
2WD ONLY! Will make a 4WD steer in opposite direction!
$275.00US

Steering Box Output Shaft (Geared), for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50
Minneapolis Moline G350, G450
Allis Chalmers 5040
Long 350, 360, 445, 460, 510, 560, 610
Fiat/Hesston 445, 450, 460, 470, 480, 480-8
500, 540, 550, 600, 640
2WD ONLY! Will make a 4WD steer in opposite direction!
$225.00US

Steering Box Output Shaft (Forked), for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50
Minneapolis Moline G350, G450
Allis Chalmers 5040
Long 350, 360, 445, 460, 510, 560, 610
Fiat/Hesston 445, 450, 460, 470, 480, 480-8
500, 540, 550, 600, 640
$199.50US

Steering Column Worm Shaft Top Bearing, for:
Oliver/Cockshutt 1250, 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50, 2-60
MM G350 & G450
AC 5045, 5050
Fiat/Hesston 420, 445, 450, 480, 480-8, 500, 540, 550, 600, 640
55-46, 60-46, 65-46, 70-46
55-56, 60-56, 65-56, 70-56
$35.00US

Steering Column Worm Shaft Bottom Bearing, for:
Oliver/Cockshutt 1250, 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50, 2-60
MM G350 & G450
AC 5045, 5050
Fiat/Hesston 420, 445, 450, 480, 480-8, 500, 540, 550, 600, 640
55-46, 60-46, 65-46, 70-46
55-56, 60-56, 65-56, 70-56
$35.00US

Steering Column Worm Shaft Top or Bottom Bearing, for:
Allis Chalmers 5040
Long 350, 360, 445, 460, 510, 550, 560
Universal UTB 350, 400, 445, 500
530, 550, 590 Super, 640

(when top and bottom bearings are identical)
Outer Race OD: 2.835" ID: 2.07"
Qty: 1 bearing. Pic for clarity
$60.00US

Steering Output Shaft, or Drop Arm Nut, for:
Oliver/Cockshutt 1250, 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50, 2-60
MM G350 & G450
AC 5045, 5050
Fiat/Hesston 420, 445, 450, 480, 480-8, 500, 540, 550, 600, 640

(For ORIGINAL steering output shafts only; NOT our replacements!)
$12.50US

Steering Box Output Shaft Seal for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50, 2-60
MM G350 & G450
AC 5040, 5045, 5050
Long 350, 360, 445, 460, 510, 550, 560
Universal UTB 350, 400, 445, 500
530, 550, 590 Super, 640
Fiat/Hesston 420, 445, 450, 480, 480-8, 500, 540, 550, 600, 640
55-46, 60-46, 65-46, 70-46
55-56, 60-56, 65-56, 70-56
$7.50US

Steering Box Column Top Bushing (brass; rubber surround) for:
Oliver/Cockshutt 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50, 2-60
MM G350 & G450
AC 5040, 5045, 5050
Long 350, 360, 445, 460, 510, 550, 560
Universal UTB 350, 400, 445, 500
530, 550, 590 Super, 640
Fiat/Hesston 420, 445, 450, 480, 480-8, 500, 540, 550, 600, 640
55-46, 60-46, 65-46, 70-46
55-56, 60-56, 65-56, 70-56
$15.00US

Steering Box Drop Arm for:
Oliver/Cockshutt 1250, 1250-A, 1255, 1265, 1355, 1365
White 1270, 1370, 2-50, 2-60
MM G350 & G450
AC 5040, 5045, 5050
Long 350, 360, 445, 460, 510, 550, 560
Universal UTB 350, 400, 445, 500
530, 550, 590 Super, 640
Fiat/Hesston 420, 445, 450, 480, 480-8, 500, 540, 550, 600, 640
$199.50US

Steering Column Assembly, for:
White 700
Fiat/Hesston 580, 680, 780, 880, 880-5, 980
$175.00US

Steering Articulation Joint Assembly, for:
Fiat / Hesston 55-90, 60-90, 65-90
70-90, 75-90, 80-90, 90-90, 100-90, 110-90
65-94, 72-94, 82-94, 88-94
PN 5124926
$250.00US
