Final Drive Parts

Except where otherwise noted, all parts on this page fit:
Oliver/Cockshutt 1250, 1250-A, 1255, 1265, 1355, 1365
Allis Chalmers 5040, 5045, 5050
White 1270, 1370, 2-50, 2-60
Minneapolis Moline G350, G450
Long 350, 360, 445, 460, 510, 550, 560, 610, 680
Fiat / Hesston 411R, 411RG, 415, 450, 480, 480-8, 500, 540, 550, 640
55-46, 55-56, 60-46, 60-56

Axle Woodruff Key
$5.00US

Final Drive Small End Bearing; goes on outer end of Drive Axle
Special Thrust Construction
80x35x21MM; check before ordering!
$59.50US

Final Drive Bearing and Seal Kit
(does one side)
includes 1 x #1, #6, & #7

$110.00US

1

Final Drive Inner Bearing

$42.50US

2

Final Drive Shaft Nut

$12.50US

3

N/A at this time

4

Final Drive Gear, for:
Oliver/Cockshutt 1250, 1250-A, 1255, 1265
Allis Chalmers 5040
White 1270
Minneapolis Moline G350
Long 350, 360, 445, 460 6 Speed
Fiat / Hesston 411R, 411RG, 415, 450, 480, 480-8
$275.00US

4
Final Drive Gear, for:
Oliver/Cockshutt 1355, 1365
Allis Chalmers 5045, 5050
White 1370, 2-50, 2-60
Minneapolis Moline G450
Long 460 8 Speed, 510, 550, 560, 610, 680
Fiat / Hesston 500, 540, 550, 640
65-46, 65-56, 70-46, 70-56
$275.00US

5

Final Drive Spacer

$12.50US

6

Final Drive Outer Bearing

$60.00US

7

Final Drive Seal

$19.50US

8

Final Drive Stub Shaft (9½" length)

$275.00US

8

Final Drive Stub Shaft (11¾" length)
this part also fits 65-46, 70-56

$275.00US

Final Drive Gasket,
13 BOLT Holes (not counting alignment dowels)

$25.00US

Final Drive Gasket,
16 BOLT Holes (not counting alignment dowels)
$25.00US
